Terex Simplicity 5x16 Wash Plant
Terex Simplicity 5x16 Wash Plant
Description
New Terex Simplicity TXW516S Portable Wash Plant, Simplicity 5 X 16 Triple Deck Inclined Two Bearing Screen, Decks to Set Up for Wire Cloth, With a 1800 RPM, TEFC Electric Motor with Screen V-belt Drive, Walkway Access Around Three sides of the Screen with an Access Ladder, Under-screen Fines Collection Flume is Made from 1/4" Plate and Has a Splash-type Spray System. Water Spray, Systems on All Screen Decks, Flume and Washout. Heavy-duty 36" x 25' Single Screw with 15 HP Drive. Manifold with the Necessary Hardware, Valves and Hoses. Roll-Away Heavy-duty Discharge Chute Made with 1/4" Plate and Lined with A.R. Plate in Heavy Wear Areas. Includes a Top Deck-overs Chute with Discharge to the Front of the Plant. The Middle Deck Chute Discharges to the Side and the Bottom Deck Discharges to the Opposite side. All Standard Guards are Included. Chassis has Heavy-duty I-beam Frame with Four Braced Support Legs and 2 Manual Landing Jacks. Includes Double Axle Suspension with Eight Tires, Fifth Wheel, Air Brakes on 2 Axles, Mud Flaps and Tail Lights. Does Not Include Wire Cloth
Specifications
Manufacturer | Terex Simplicity |
Model | 5x16 Wash Plant |
Condition | New |
Serial Number | TXW516S202 |
